Hey, I think I understand what are you asking, although, I think it would take great mental effort to verify it (it is easy to see the diglet's schematic but I'd have to process my own pictures)... however I can avoid spending that effort by stating that I never cared whether I connect 1 or 3, because transformer is a passive component that is symmetrical in regards to input (another way to say "ac component lol", I am sure other engineers here can try to make me speak "proper" academic language). So, it functions the same in both ways, I only cared to make sure all 3 transformers are wired consistently - meaning that I cared about wiring inputs the same on all 3, and outputs the same on all 3, to make sure signal phases are not inverted for only one channel somewhere (if you invert all 3 - it is still same complex signal).nopr4me wrote: Fri Oct 10, 2025 6:25 am Hi edger,
A quick question about your breadboard: it looks as though you have connected together the number 3 input terminals of the transformers at F2, Q2, A2 compared to diglet's schematic where the number 2 terminals are connected. And your inputs come in on the number 2 terminals at F4, Q4 and A4. Is this correct?
Thanks
Since you seem very capable of reading the schematics properly and mapping them to actual breadboard/wires, feel free to build your box according to the actual schematic, I can guarantee you that it will not make it any worse (and it might make it better in a sense that you will feel achievement from not simply reproducing something in identical manner but building your own).
